PILZ - 750126 - Safety Relay, 24 VDC, 3PST-NO, PNOZ s6.1, DIN Rail, 6 A, Screw
- Coil Voltage: 24VDC
- Contact Configuration: 3PST-NO
- Product Range: PNOZ s6.1 Series
- Relay Mounting: DIN Rail
- Contact Current: 6A
- Relay Terminals: Screw
- Contact Voltage AC Nom: 240V
- Contact Voltage DC Nom: 24V
- Contact Material: Silver Copper Nickel
- IP Rating: IP20, IP40, IP54
- SVHC: No SVHC (15-Jan-2019)
- Approval Bodies: BG, CCC, UL
- Approval Category: EN 574 TYPE III A, EN 954-1, EN 60204-1, EN 62061, VDE 0113-1
- Approvals / Standards: EN 60204, EN 60947, EN 62061, IEC 61511, ISO 13849
- Coil Voltage VDC Nom: 24V
- Contact Current Max: 8A
- External Depth: 120mm
- External Height: 98mm
- External Length / Height: 98mm
- External Width: 22.5mm
- Operating Temperature Max: 55°C
- Operating Temperature Min: -10°C
- Performance Level: PL c
- Relay Type: Safety
- Safety Category: Level 3
- Safety Integrity Level: SIL2, SIL CL2
- Supply Voltage V DC: 24VDC
- Switch Current Max: 8A
- Switching Current Max: 8A
- Type: Safety monitoring
