PILZ - 751134 - Safety Relay, 240 V, 3PST-NO, PNOZ s4, DIN Rail, 6 A, Spring Clamp
- Coil Voltage: 240V
- Contact Configuration: 3PST-NO
- Product Range: PNOZ s4 Series
- Relay Mounting: DIN Rail
- Contact Current: 6A
- Relay Terminals: Spring Clamp
- Contact Voltage AC Nom: 240V
- Contact Voltage DC Nom: 24V
- Contact Material: Silver Copper Nickel
- IP Rating: IP20, IP40, IP54
- SVHC: No SVHC (15-Jan-2019)
- Approvals / Standards: EN 60204, EN ISO 13849
- Coil Voltage VAC Nom: 240V
- Coil Voltage VDC Nom: 240V
- Contact Current Max: 6A
- External Depth: 120mm
- External Height: 102mm
- External Width: 22.5mm
- Performance Level: PL e
- Safety Category: CATIV
- Safety Integrity Level: SIL3, SIL CL3
