Omschrijving
MURATA POWER SOLUTIONS - 77204C - Pulse Transformer, PCB, 1:1, 4 mH, 0.86 ohm, 240 Vµs, 2.5 kV, 77204C Series
- TRANSFORMER, PULSE, 1: 1, 8DIP
- Turns Ratio: 1
- Isolation Voltage: 2.5kV
- Product Range: 772 Series
- Inductance: 4mH
- DC Resistance: 0.86ohm
- ET Constant: 240Vµs
- SVHC: No SVHC (07-Jul-2017)
- Capacitance: 55pF
- External Depth: 12.3mm
- External Length / Height: 25.4mm
- External Width: 20.3mm
- Flammability Rating: UL94V-0
- Leakage Inductance: 5µH
- Operating Temperature Max: 70°C
- Operating Temperature Min: 0°C
- Primary Inductance: 4mH
- Secondary Resistance: 0.86ohm
- Transformer Type: Pulse
- Winding Configuration: 1
- Winding Resistance Max: 0.83ohm
