8-1393243-5 Relay, Power, Pcb, 24Vdc, 8A SCHRACK - Te Connectivity

SCHRACK - TE CONNECTIVITYSKU:8-1393243-5 Bestelcode:2060858

Prijs:
Actie prijs€12,29

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (2280 units)

Documenten en downloads

Omschrijving

SCHRACK - TE CONNECTIVITY - 8-1393243-5 - General Purpose Relay, RT2 Series, Power, Non Latching, DPDT, 24 VDC

  • Contact Configuration: DPDT
  • Coil Voltage: 24VDC
  • Contact Current: 15A
  • Product Range: RT2 Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250V
  • Relay Terminals: Solder
  • Contact Voltage VDC: -
  • Contact Material: Silver Nickel
  • Coil Resistance: 1.4kohm
  • SVHC: No SVHC (15-Jan-2019)
  • Approvals & Standards: CSA, UL, VDE
  • Coil Voltage VDC Nom: 24V
  • Contact Current Max: 8A
  • Contact Voltage AC Nom: 250V
  • External Depth: 29mm
  • External Height: 15.7mm
  • External Width: 12.7mm
  • Nom Operating Power: 400mW
  • Relay Type: Power
