8340-F410-P1M2-A2H0-10A Circuit Breaker, HYDROMAGNETIC, 10A ETA

ETASKU:8340-F410-P1M2-A2H0-10A Bestelcode:9540733

Prijs:
Actie prijs€55,61

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (8 units)

Documenten en downloads

Omschrijving

ETA - 8340-F410-P1M2-A2H0-10A - Magnetic Hydraulic Circuit Breaker, 8340, 10 A, 1 Pole, 2 kA

  • Product Range: 8340 Series
  • Current Rating: 10A
  • No. of Poles: 1 Pole
  • Input Voltage VAC: -
  • Interrupting Capacity: 2kA
  • Trip Time: -
  • Dielectric Strength: -
  • SVHC: No SVHC (15-Jan-2018)
  • Approval Bodies: BUREAU VERITAS, CSA, EN, LLOYDS, QPL, UL, VDE
  • Breaking Capacity Current AC: 3500A
  • Breaking Capacity Current DC: 3500A
  • External Depth: 50.8mm
  • External Length / Height: 50.8mm
  • External Width: 15mm
  • Fixing Centres: 42.15mm
  • Fuse Current: 10A
  • Insulation Resistance: 100Mohm
  • Internal Resistance: 0.02ohm
  • No. of Mechanical Operations: 10000
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -40°C
  • Termination Method: Tab
  • Thread Depth: 4.5mm
  • Thread Size: M3
  • Voltage Rating V DC: 80V
  • Voltage Rating VAC: 240V
