BELDEN - 8471NH.00305 - Multipair Cable, Audio Control, Unscreened, 1 Pair, 16 AWG, 1.3 mm², 1000 ft, 304.8 m
- Cable Shielding: Unscreened
- No. of Pairs: 1 Pair
- Wire Gauge: 16AWG
- Conductor Area CSA: 1.3mm²
- Reel Length (Imperial): 1000ft
- Reel Length (Metric): 304.8m
- Jacket Colour: Chrome
- No. of Max Strands x Strand Size: 19 x 0.286mm
- Voltage Rating: 300V
- Jacket Material: LSZH
- Conductor Material: Tinned Copper
- External Diameter: 7.15mm
- Product Range: -
- SVHC: No SVHC (15-Jan-2018)
- Belden Type Number: 8471NH
- Cable Type: Unshielded
- Cable UL Style Number: UL2598
- Complex Cable Make-Up: 2 x 19/29
- Conductor Make-up: 19 / 29AWG
- Operating Temperature Max: 80°C
- Operating Temperature Min: -15°C
- Primary Conductor Resistance: 32.8ohm/km
- Secondary Insulation Colour: Chrome
- Secondary Insulation Material: PVC
- Velocity of Propagation (%): 67%
- Wire Size: 16AWG
