WAGO - 859-794 - DIN Rail Mount Terminal Block, With Switching Relay, 5 Ways, 28 AWG, 14 AWG, 2.5 mm², Clamp
- No. of Positions: 5Ways
- Wire Size AWG Min: 28AWG
- Wire Size AWG Max: 14AWG
- Conductor Area CSA: 2.5mm²
- Wire Connection Method: Clamp
- Rated Current: -
- Rated Voltage: -
- No. of Levels: 2
- Product Range: 859 Series
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: IEC
- Connector Mounting: DIN Rail Mount
- Connector Type: Terminal Block, DIN Rail
- External Depth: 56mm
- External Length / Height: 91mm
- External Width: 9mm
- Frequency Max: 1.5kHz
- Height: 91mm
- Input Voltage Max: 30V
- Input Voltage Min: 18V
- Nom Operating Voltage: 24V
- Operating Temperature Max: 60°C
- Operating Temperature Min: -25°C
- Output Voltage: 60V
- Output Voltage Max: 60V
- Output Voltage Min: 20V
