9L0412H301 FAN, LONG LIFE, 40MM, 12VDC SANYO DENKI

SANYO DENKISKU:9L0412H301 Bestelcode:1318956

Prijs:
Actie prijs€46,53

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (426 units)

Documenten en downloads

Omschrijving

SANYO DENKI - 9L0412H301 - DC Axial Fan, 12 V, Square, 40 mm, 28 mm, Ball Bearing, 13.06 CFM

  • Supply Voltage: 12V
  • Current Type: DC
  • Fan Frame Size: 40mm
  • External Depth: 28mm
  • Noise Rating: 40dBA
  • Flow Rate - Imperial: 13.06cu.ft/min
  • Flow Rate - Metric: 0.37m³/min
  • Bearing Type: Ball
  • Power Connection Type: 3 Lead Wires
  • Current Rating: 150mA
  • Product Range: San Ace 40L Series
  • Power Rating: 1.8W
  • IP Rating: -
  • SVHC: No SVHC (15-Jun-2015)
  • Case Material: Aluminium
  • External Height: 40mm
  • External Width: 40mm
  • Fixing Centres: 32mm
  • Fixing Hole Diameter: 3.5mm
  • Frame Dimensions: 40mm x 40mm x 28mm
  • Input Power: 1.8W
  • Material: Plastic
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -10°C
  • Operating life Time: 100000h
  • Panel Cutout Diameter: 38mm
  • Power Consumption: 1.8W
  • Pressure Max: 106Pa
  • Speed Range Max: 8400rpm
  • Supply Voltage DC Max: 13.8VDC
  • Supply Voltage DC Min: 10.2VDC
  • Weight: 55g
