AB05 2100 14 19 SN00 Socket, Panel, 19WAY TT Electronics / Ab Connectors

TT ELECTRONICS / AB CONNECTORSSKU:AB05 2100 14 19 SN00 Bestelcode:107923

Prijs:
Actie prijs€99,94

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (13 units)

Documenten en downloads

Omschrijving

TT ELECTRONICS / AB CONNECTORS - AB05 2100 14 19 SN00 - Circular Connector, AB05, Wall Mount Receptacle, 19 Contacts, Solder Socket, Bayonet, 14-19

  • Product Range: AB05 Series
  • Circular Connector Shell Style: Wall Mount Receptacle
  • No. of Contacts: 19Contacts
  • Circular Contact Type: Solder Socket
  • Coupling Style: Bayonet
  • Insert Arrangement: 14-19
  • Connector Body Material: Aluminium Alloy Body
  • Connector Body Plating: Olive Drab Chromate over Cadmium
  • Contact Material: Brass
  • Contact Plating: Gold
  • Insert Rotation: N
  • Service Class: Corrosion Resistant
  • Equivalent Military Specification: MIL-DTL-26482 Series I
  • Colour: Olive
  • Contact Resistance: 5mohm
  • Current Rating: 5A
  • External Length / Height: 26.4mm
  • External Width: 29mm
  • IP / NEMA Rating: IP67
  • No. of Mating Cycles: 500
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -55°C
  • Panel Cutout Diameter: 25.12mm
  • Panel Cutout Size: 23.01 mm
  • Voltage Rating VAC: 700V
  • Working Voltage: 700V
