AB05 6027 12 10 PN00 Plug, Free, 10WAY TT Electronics / Ab Connectors

TT ELECTRONICS / AB CONNECTORS - AB05 6027 12 10 PN00 - Circular Connector, AB05, Straight Plug, 10 Contacts, Solder Pin, Bayonet, 12-10

• Product Range: AB05 Series
• Circular Connector Shell Style: Straight Plug
• No. of Contacts: 10Contacts
• Circular Contact Type: Solder Pin
• Coupling Style: Bayonet
• Insert Arrangement: 12-10
• Connector Body Material: Aluminium Alloy Body
• Connector Body Plating: Olive Drab Chromate over Cadmium
• Contact Material: Brass
• Contact Plating: Gold
• Insert Rotation: N
• Service Class: Corrosion Resistant
• Equivalent Military Specification: MIL-DTL-26482 Series I
• Approval Bodies: BS
• Cable Diameter Max: 8.3mm
• Colour: Olive
• Contact Gender: Pin
• Contact Resistance: 5mohm
• Coupling Diameter: 26.4mm
• Current Rating: 5A
• External Length / Height: 51.33mm
• IP / NEMA Rating: IP67
• No. of Mating Cycles: 500
• Operating Temperature Max: 125°C
• Operating Temperature Min: -55°C
• Voltage Rating VAC: 700V
• Working Voltage: 700V
