ABB00T 10SL3PSNB10SLRPG Plug, 3WAY TT Electronics / Ab Connectors

TT ELECTRONICS / AB CONNECTORSSKU:ABB00T 10SL3PSNB10SLRPG Bestelcode:107957

Prijs:
Actie prijs€41,08

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (240 units)

Documenten en downloads

Omschrijving

TT ELECTRONICS / AB CONNECTORS - ABB00T 10SL3PSNB10SLRPG - Circular Connector, ABB, Wall Mount Receptacle, 3 Contacts, Solder Pin, Bayonet, 10SL-3

  • Product Range: ABB Series
  • Circular Connector Shell Style: Wall Mount Receptacle
  • No. of Contacts: 3Contacts
  • Circular Contact Type: Solder Pin
  • Coupling Style: Bayonet
  • Insert Arrangement: 10SL-3
  • Connector Body Material: Aluminium Alloy Body
  • Connector Body Plating: Olive Drab Chromate over Cadmium
  • Contact Material: Copper Alloy
  • Contact Plating: Silver
  • Insert Rotation: N
  • Service Class: Environmentally Sealed
  • Equivalent Military Specification: MIL-DTL-5015 Series
  • Approval Bodies: BS
  • Cable Diameter Max: 2.77mm
  • Cable Diameter Min: 1.68mm
  • Colour: Olive
  • Current Rating: 10A
  • Current per Power Contact Max: 10A
  • External Length / Height: 29.5mm
  • External Width: 25.7mm
  • Height: 29.5mm
  • IP / NEMA Rating: IP67
  • No. of Mating Cycles: 500
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -55°C
  • Panel Cutout Diameter: 16.13mm
  • Panel Cutout Size: 18.2 mm
  • Voltage Rating VAC: 350V
  • Working Voltage: 350V
