BLOCK - AVB1.5/2/15 - PCB Transformer, Safety, Encapsulated Safety Isolating, 2 x 115V, 2 x 15V, 1.5 VA, 50Hz / 60Hz
- Power Rating: 1.5VA
- Secondary Voltages: 2 x 15V
- Current Rating: 50mA
- Isolation Transformer Primary Voltages: 2 x 115V
- Plug Type: -
- Product Range: -
- SVHC: No SVHC (12-Jan-2017)
- AC Power: 1.5VA
- Approval Bodies: CSA, UL, VDE
- External Depth: 23.8mm
- External Length / Height: 27.3mm
- External Width: 32.3mm
- Flammability Rating: UL94V-0
- Hole Spacing - Length: 20mm
- Input Voltage: 230V
- Isolation Voltage: 5kV
- Lead Spacing: 5mm
- Output 2 Voltage Max: 15V
- Output Voltage: 15V
- Pin Diameter: 0.8mm
- Pin Length: 5mm
- Pitch Spacing: 5mm
- Primary Voltages: 2 x 115V
- Regulation: 57%
- Secondary Current Nom: 50mA
- Secondary Power: 0.75VA
- Supply Voltage V AC: 230V
- Transformer Type: Isolation
- Weight: 84g
