B41560A8229M000 Cap, 22000µF, 63V, Alu Elec, Screw EPCOS

EPCOSSKU:B41560A8229M000 Bestelcode:4704940

Prijs:
Actie prijs€38,07

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (46 units)

Documenten en downloads

Omschrijving

EPCOS - B41560A8229M000 - Electrolytic Capacitor, High Ripple, 22000 µF, 63 V, ± 20%, Screw, 3000 hours @ 105°C

  • Capacitance: 22000µF
  • Voltage Rating: 63V
  • Product Range: B41560 Series
  • Lifetime @ Temperature: 3000 hours @ 105°C
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Screw
  • Diameter: 51.6mm
  • Lead Spacing: 22.2mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 105°C
  • Height: 105mm
  • ESR: 0.016ohm
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (27-Jun-2018)
  • Capacitance Tolerance ±: ± 20%
  • Climatic Category: 40/105/56
  • External Length / Height: 105.7mm
  • Impedance: 16mohm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +105°C
  • Operating life Time: 3000h
  • Ripple Current AC: 12A
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 63V
