B43504A5337M000 Cap, 330µF, 450V, Alu Elec, Snap In EPCOS

EPCOSSKU:B43504A5337M000 Bestelcode:1219075

Prijs:
Actie prijs€16,28

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (253 units)

Documenten en downloads

Omschrijving

EPCOS - B43504A5337M000 - Electrolytic Capacitor, Snap-in, 330 µF, 450 V, ± 20%, Snap-In, 3000 hours @ 105°C

  • Capacitance: 330µF
  • Voltage Rating: 450V
  • Product Range: B43504 Series
  • Lifetime @ Temperature: 3000 hours @ 105°C
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Quick Connect, Snap-In
  • Diameter: 30mm
  • Lead Spacing: 10mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 105°C
  • Height: 50mm
  • ESR: 0.41ohm
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Category: IEC 384-4
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 50mm
  • Impedance: 490mohm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +105°C
  • Operating life Time: 2000h
  • Ripple Current AC: 1.6A
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 450V
