Omschrijving
EPCOS - B43504A9337M000 - Electrolytic Capacitor, Snap-in, 330 µF, 400 V, ± 20%, Snap-In, 3000 hours @ 105°C
- Capacitance: 330µF
- Voltage Rating: 400V
- Product Range: B43504 Series
- Lifetime @ Temperature: 3000 hours @ 105°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Quick Connect, Snap-In
- Diameter: 30mm
- Lead Spacing: 10mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Height: 45mm
- ESR: 0.27ohm
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- Approval Category: IEC 384-4
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 45mm
- Impedance: 330mohm
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +105°C
- Operating life Time: 2000h
- Ripple Current AC: 1.5A
- Ripple Current Temperature: 105°C
- Tolerance +: 20%
- Tolerance -: 20%
- Voltage Rating V DC: 400V
