B72205S0750K101 Varistor, 2.5J, 75VAC EPCOS

EPCOSSKU:B72205S0750K101 Bestelcode:1004343

Prijs:
Actie prijs€0,39

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (1426 units)

Documenten en downloads

Omschrijving

EPCOS - B72205S0750K101 - TVS Varistor, 75 V, 100 V, B722 Series, 200 V, Disc 5mm, Metal Oxide Varistor (MOV)

  • Voltage Rating VAC: 75V
  • Voltage Rating V DC: 100V
  • Product Range: B722 Series
  • Clamping Voltage Vc Max: 200V
  • Varistor Case Style: Disc 5mm
  • Varistor Type: Metal Oxide Varistor (MOV)
  • Peak Surge Current @ 8/20µs: 400A
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Peak Energy (10/1000uS): 2.5J
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Bodies: CECC, CSA, UL
  • Body Diameter: 7mm
  • Capacitance: 210pF
  • Clamping Voltage: 200V
  • Clamping Voltage @ 8/20µs Max: 200V
  • External Length / Height: 9.5mm
  • Lead Length: 30mm
  • Operating Temperature Range: -40°C to +85°C
  • Peak Pulse Current IPP @ 8/20µs: 400A
  • Suppressor Type: Varistor
  • Surge Current: 400A
  • Transient Energy: 2.5J
  • Varistor Voltage: 120V
  • Varistor Voltage @ 1mA: 108V
  • Varistor Voltage @ 1mA Max: 132V
  • Varistor Voltage Tolerance +: 10%
