EPCOS - B72214Q0321K101 - TVS Varistor, 320 V, 420 V, B722 Series, 840 V, Disc 14mm, Metal Oxide Varistor (MOV)
- Voltage Rating VAC: 320V
- Voltage Rating V DC: 420V
- Product Range: B722 Series
- Clamping Voltage Vc Max: 840V
- Varistor Case Style: Disc 14mm
- Varistor Type: Metal Oxide Varistor (MOV)
- Peak Surge Current @ 8/20µs: 8kA
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Peak Energy (10/1000uS): 185J
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: CECC, CSA, UL
- Capacitance: 390pF
- Clamping Current Max: 65A
- Clamping Voltage: 840V
- Clamping Voltage @ 8/20µs Max: 840V
- External Depth: 6.3mm
- External Length / Height: 16.5mm
- External Width: 16.5mm
- Lead Diameter: 1mm
- Lead Length: 30mm
- Lead Spacing: 10mm
- Operating Temperature Range: -40°C to +85°C
- Peak Pulse Current IPP @ 8/20µs: 8000A
- Power Dissipation Ptot Max: 0.8W
- Response Time: 25ns
- Suppressor Type: Varistor
- Surge Current: 8kA
- Transient Energy: 185J
- Varistor Voltage: 510V
- Varistor Voltage @ 1mA: 459V
- Varistor Voltage @ 1mA Max: 561V
- Varistor Voltage Tolerance +: 10%
