KEMET - C4BSNBX4100ZBFJ - Power Film Capacitor, Metallized PP, Radial Box - Tabs, 1 µF, ± 5%, Snubber, Panel Mount
- Capacitance: 1µF
- Voltage Rating: 1kV
- Capacitor Dielectric Type: PP (Polypropylene)
- Capacitance Tolerance: ± 5%
- Product Range: C4BS Series
- Capacitor Case Style: Radial Box
- Capacitor Terminals: Solder Lug
- Lead Spacing: 6mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 5%
- Capacitor Application: Automotive Qualified
- Capacitor Mounting: Panel
- ESR: 0.0037ohm
- External Depth: 40mm
- External Length / Height: 20mm
- External Width: 41.5mm
- Height: 20mm
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +85°C
- Voltage Rating V DC: 1kV
