CSTBV23/2 Terminal Block, Wire TO BRD, 2Pos, 16AWG Camdenboss

CAMDENBOSSSKU:CSTBV23/2 Bestelcode:1425645

Prijs:
Actie prijs€5,77

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (10 units)

Documenten en downloads

Omschrijving

CAMDENBOSS - CSTBV23/2 - Standard Terminal Block, Wire to Board, CSTBV23, 2 Contacts, 5.08 mm, Terminal Block, PCB

  • Product Range: CSTBV23 Series
  • No. of Contacts: 2Contacts
  • Pitch Spacing: 5.08mm
  • Connector Type: Terminal Block, PCB
  • Connector Mounting: PCB Mount
  • Wire Size AWG Max: 16AWG
  • Wire Size AWG Min: 30AWG
  • Contact Plating: Tin Plated Contacts
  • Contact Material: Phosphor Bronze
  • SVHC: No SVHC (15-Jan-2019)
  • Block Orientation: Through Hole Right Angle
  • Colour: Grey
  • Conductor Area CSA: 1.5mm²
  • Current Rating: 16A
  • External Length / Height: 10.16mm
  • Height: 10.16mm
  • Insulation Resistance: 5Mohm
  • Material: UL94-V0 Flame Retardant PA66
  • No. of Positions: 2Ways
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -20°C
  • Rated Current: 10A
  • Rated Voltage: 300V
  • Screw Material: Zinc Plated Steel
  • Temperature Max: +125°C
  • Temperature Min: -20°C
  • Voltage Rating VAC: 320V
  • Wire Area Size Max: 1.5mm²
  • Wire Connection Method: Clamp
  • Wire Size (AWG): 30AWG to 16AWG
  • Wire Size Range (AWG): 18-16
