CAMDENBOSS - CTB9208/2 - Pluggable Terminal Block, 5.08 mm, 2 Ways, 30AWG to 12AWG, 2.5 mm², Screw, 12 A
- Pitch Spacing: 5.08mm
- No. of Positions: 2Ways
- Wire Size (AWG): 30AWG to 12AWG
- Conductor Area CSA: 2.5mm²
- Wire Connection Method: Screw
- Rated Current: 12A
- Rated Voltage: 320V
- Product Range: CTB9208 Series
- SVHC: No SVHC (15-Jan-2019)
- Cable Diameter Max: 2.5mm
- Colour: Green
- Connector Mounting: Cable Mount
- Connector Type: Terminal Block, Pluggable
- Contact Material: Phosphor Bronze
- Contact Plating: Tin Plated Contacts
- Current Rating: 12A
- Insulation Resistance: 5Mohm
- Length: 10.16mm
- Material: UL94-V0 Flame Retardant PA66
- No. of Contacts: 2Contacts
- Operating Temperature Max: 125°C
- Operating Temperature Min: -20°C
- Wire Size AWG Max: 12AWG
- Wire Size AWG Min: 30AWG
- Wire Size Range (AWG): 10
- Withstand Voltage: 2.5kV
- Working Voltage: 380V
