CTB9400/3 Terminal Block, Pluggable, 3Pos, 12AWG Camdenboss

CAMDENBOSSSKU:CTB9400/3 Bestelcode:3882287

Prijs:
Actie prijs€7,20

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (452 units)

Documenten en downloads

Omschrijving

CAMDENBOSS - CTB9400/3 - Pluggable Terminal Block, 7.5 mm, 3 Ways, 30AWG to 12AWG, 2.5 mm², Screw, 12 A

  • Pitch Spacing: 7.5mm
  • No. of Positions: 3Ways
  • Wire Size (AWG): 30AWG to 12AWG
  • Conductor Area CSA: 2.5mm²
  • Wire Connection Method: Screw
  • Rated Current: 12A
  • Rated Voltage: 500V
  • Product Range: CTB9400 Series
  • SVHC: No SVHC (15-Jan-2019)
  • Colour: Green
  • Connector Mounting: Cable Mount
  • Connector Type: Terminal Block, Pluggable
  • Contact Material: Brass
  • Contact Plating: Copper Plated Contacts
  • Current Rating: 12.0A
  • Flammability Rating: UL94V-0
  • No. of Contacts: 3Contacts
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -20°C
  • Screw Material: Steel
  • Screw Plating: Zinc
  • Thread Size: M3
  • Voltage Rating AC Max: 750V
  • Voltage Rating VAC: 750V
  • Wire Area Size Max: 2.5mm²
  • Wire Size AWG Max: 12AWG
  • Wire Size AWG Min: 30AWG
