OMRON - D2VW-5L3-1MS - Microswitch, Snap Action, Simulated Roller Lever, SPDT-1NO / 1NC, Quick Connect, Solder, 5 A
- Microswitch Type: Snap Action
- Microswitch Actuator: Simulated Roller Lever
- Contact Configuration: SPDT-1NO / 1NC
- Switch Terminals: Quick Connect, Solder
- Contact Current Max: 5A
- Contact Voltage DC Nom: 250VDC
- Product Range: D2VW Series
- Contact Voltage AC Nom: 250VAC
- Operating Force Max: 120gf
- Actuation Type: Simulated Roller Lever
- Actuator Type: Simulated Roller Lever
- Contact Current AC Max: 5A
- Contact Current DC Max: 5A
- Contact Voltage AC Max: 250V
- Contact Voltage DC Max: 250V
- Operating Force: 1.18N
