Omschrijving
CINCH CONNECTIVITY SOLUTIONS - DB25P - D Sub Connector, DB25, Standard, Plug, Basic D Series, 25 Contacts, DB, Solder Cup
- No. of Contacts: 25Contacts
- Gender: Plug
- Contact Termination Type: Solder Cup
- D Sub Shell Size: DB
- Product Range: Basic D Series
- Connector Body Material: Metal Body
- Contact Material: -
- Contact Plating: -
- SVHC: No SVHC (15-Jan-2018)
- Connector Mounting: Cable Mount
- Contact Resistance: 2.7mohm
- Contact Termination: Solder
- Current Rating: 5A
- D Sub Connector Type: Standard
- Flammability Rating: UL94V-0
- Insulation Resistance: 5000Mohm
- Material: Steel with zinc plating
- No. of Mating Cycles: 500
- Operating Temperature Max: 125°C
- Operating Temperature Min: -65°C
- Termination Method: Solder Bucket
- Withstand Voltage: 1250V
