DC-37P-OL2-K87 Connector, Straight Pcb, Plug, 37 Way ITT Cannon

ITT CANNONSKU:DC-37P-OL2-K87 Bestelcode:1760338

Prijs:
Actie prijs€36,75

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (14 units)

Documenten en downloads

Omschrijving

ITT CANNON - DC-37P-OL2-K87 - D Sub Connector, DB37, Standard, Plug, DC, 37 Contacts, DC, Solder

  • No. of Contacts: 37Contacts
  • Gender: Plug
  • Contact Termination Type: Solder
  • D Sub Shell Size: DC
  • Product Range: DC Series
  • Connector Body Material: Metal Body
  • Contact Material: -
  • Contact Plating: -
  • Body Plating: Tin
  • Connector Mounting: Through Hole Mount
  • Contact Resistance: 10mohm
  • Contact Termination: Solder
  • Current Rating: 5A
  • D Sub Connector Type: Standard
  • Flammability Rating: UL94V-0
  • Material: Steel
  • No. of Mating Cycles: 200
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -55°C
  • Termination Method: Solder
  • Withstand Voltage: 1250V
