DD12-24 072 Converter, DC/DC, 72W, 24V ALFATRONIX

ALFATRONIXSKU:DD12-24 072 Bestelcode:1184212

Prijs:
Actie prijs€191,65

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (16 units)

Documenten en downloads

Omschrijving

ALFATRONIX - DD12-24 072 - Non Isolated POL DC/DC Converter, Step Up, ITE, 1 Output, 72 W, 24 V, 3 A, Fixed, Adjustable

  • No. of Outputs: 1 Output
  • Output Power Max: 72W
  • Output Voltage Nom.: 24V
  • Output Current Max: 3A
  • DC / DC Converter Output Type: Fixed, Adjustable
  • DC / DC Converter Mounting: Panel
  • Input Voltage DC Min: 10V
  • Input Voltage DC Max: 15V
  • DC / DC Converter Type: Module
  • Depth: 50mm
  • Width: 87mm
  • Height: 89mm
  • Product Range: DD Series
  • SVHC: No SVHC (07-Jul-2017)
  • Approval Bodies: CE
  • Approvals & Standards: CE
  • Continuous Power Rating: 72W
  • Efficiency: 90%
  • External Depth: 50mm
  • External Length / Height: 89mm
  • External Width: 87mm
  • Input Voltage Max: 15.6V
  • Input Voltage Min: 8.4V
  • Isolation Voltage: 400V
  • No. of Outputs: 1Outputs
  • Off Load Current: 100mA
  • Operating Temperature Max: 30°C
  • Operating Temperature Min: -25°C
  • Output Current: 27.2A
  • Output Power (Pout): 24V dc
  • Output Ripple Voltage pk-pk: 50mV
  • Output Voltage: 27.2V
  • Power Rating: 72W
  • Supply Voltage: 15.6V
  • Weight: 290g
