EATON MOELLER - DILER-22(380V50HZ,440V60HZ) - Contactor, DIN Rail, Panel, 600 VAC, DPST-NO, DPST-NC, 4 Pole
- Load Current Inductive: -
- Relay Mounting: DIN Rail, Panel
- Operating Voltage: 600VAC
- Contact Configuration: DPST-NO, DPST-NC
- No. of Poles: 4 Pole
- Switching Power AC3: -
- Switching Current AC1: -
- Coil Voltage VAC Nom: 440V
- Coil Voltage VDC Nom: -
- Switching Power AC1: -
- Load Current Resistive: -
- Switching Current AC3: -
- Product Range: DILER
- SVHC: No SVHC (17-Dec-2015)
- Approval Bodies: CSA, EN, IEC, UL, VDE
- Coil Voltage: 440V
- Coil Voltage Max: 440V
- Coil Voltage Min: 380V
- Contact Current: 6A
- Contact Current Max: 6A
- Contact Voltage AC Max: 690V
- Contact Voltage AC Nom: 415V
- Contact Voltage VAC: 690V
- Current Rating: 6A
- External Depth: 52mm
- External Height: 58mm
- External Length / Height: 58mm
- External Width: 45mm
- Frequency Max: 60Hz
- Frequency Min: 50Hz
- IP / NEMA Rating: IP20
- Insulation Voltage: 690VAC
- Nom Operating Power: 200mW
- Relay Terminals: Screw
- Relay Type: Contactor
