DRA1-CMXE60D10 SSR, DIN Rail Mount, 60VDC, 28VDC, 10A SENSATA/Crydom

SENSATA/CRYDOMSKU:DRA1-CMXE60D10 Bestelcode:1784040

Prijs:
Actie prijs€118,42

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (447 units)

Documenten en downloads

Omschrijving

SENSATA/CRYDOM - DRA1-CMXE60D10 - Solid State Relay, SPST-NO, 10 A, 60 VDC, DIN Rail, Cage Clamp

  • Contact Configuration: SPST-NO
  • Load Current: 10A
  • Operating Voltage Max: 60VDC
  • Relay Mounting: DIN Rail
  • Relay Terminals: Cage Clamp
  • Switching Mode: -
  • Operating Voltage Min: 1VDC
  • Control Voltage Min: 20VDC
  • Control Voltage Max: 28VDC
  • Product Range: -
  • SVHC: No SVHC (12-Jan-2017)
  • Control Current @ 5VDC: 15mA
  • Control Voltage DC Max: 28VDC
  • Control Voltage DC Min: 20VDC
  • Control Voltage Range: 20V DC to 28V DC
  • Control Voltage Type: DC
  • Isolation Voltage: 2.5kV
  • Load Current RMS Max: 8A
  • Operating Voltage Range: 1V DC to 60V DC
  • Peak Surge Current: 100A
  • RMS Load Current Min: 0A
  • RMS Load Voltage Max: 60V
  • RMS Load Voltage Min: 1V
  • Surge Current: 100A
