MICROCHIP - DSPIC30F6010A-30I/PF - Digital Signal Controller, dsPIC30F, 40 MHz, 144 KB, 68 I/O's, CAN, I2C, SPI, UART, 5.5 V
- Product Range: dsPIC30F Series
- Core Frequency: 40MHz
- Flash Memory Size: 144KB
- No. of I/O's: 68I/O's
- Embedded Interface Type: CAN, I2C, SPI, UART
- Core Supply Voltage: 5.5V
- DSC Case Style: TQFP
- No. of Pins: 80Pins
- Supply Voltage Min: 4.5V
- Supply Voltage Max: 5.5V
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Automotive Qualification Standard: AEC-Q100
- RoHS Phthalates Compliant: Yes
- MSL: MSL 3 - 168 hours
- SVHC: No SVHC (27-Jun-2018)
- Controller Family/Series: dsPIC
- EEPROM Memory Size: 4KB
- MPU Core Size: 16bit
- No. of ADC Inputs: 16
- No. of PWM Channels: 16
- No. of Timers: 5
- Operating Temperature Range: -40°C to +85°C
- Program Memory Size: 144KB
- RAM Memory Size: 8KB
- Supply Voltage Range: 2.5V to 5.5V
- Termination Type: Surface Mount Device
