CROMPTON - TE CONNECTIVITY - E244-01R-G-HG-ZU - Analogue Panel Meter, Shock Resistant, Calibrated at 23°C, DC Current, 4mA to 20mA, 92 mm, 92 mm
- Meter Function: DC Current
- Meter Range: 4mA to 20mA
- Panel Cutout Height: 92mm
- Panel Cutout Width: 94mm
- Product Range: E244 Series
- Accuracy Class: Class 1.5
- Approval Bodies: BV, LRS
- External Depth: 64mm
- External Length / Height: 96mm
- External Width: 96mm
- Full Scale Reading: 20 mA
- Humidity: 95%
- IP / NEMA Rating: IP54
- Meter Movement Angle: 90°
- Meter Size/Dimensions: 96mm x 96mm x 53mm
- Operating Temperature Max: 60°C
- Operating Temperature Min: -20°C
- Panel Cutout Depth: 94mm
- Power Rating: 500mVA
- Safety Category: IEC414
- Scale: 4 - 20mA
- Scale Length: 94mm
