ECM40UT32 POWER SUPPLY, AC-DC, MEDICAL, 3O/P, 40W XP POWER

XP POWERSKU:ECM40UT32 Bestelcode:1176971

Prijs:
Actie prijs€81,40

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (24 units)

Documenten en downloads

Omschrijving

XP POWER - ECM40UT32 - AC/DC Open Frame Power Supply (PSU), ITE & Medical, 3 Output, 40 W, 90V AC to 264V AC, Fixed

  • No. of Outputs: 3 Output
  • Power Rating (Covection Cooling): 40W
  • Power Rating (Forced Cooling): -
  • Input Voltage VAC: 90V AC to 264V AC
  • Power Supply Output Type: Fixed
  • Output Voltage - Output 1: 5V
  • Output Current - Output 1: 6A
  • Output Voltage - Output 2: 24V
  • Output Current - Output 2: 1A
  • Output Voltage - Output 3: -12V
  • Output Current - Output 3: 500mA
  • Output Voltage - Output 4: -
  • Current, Output 4: -
  • Product Range: ECM Series
  • SVHC: No SVHC (15-Jan-2018)
  • Approval Bodies: cUL, EN, IEC, UL
  • Approvals / Standards: CSA 22.2 No. 60601, EN 60601, ES 60601
  • Efficiency: 85%
  • Height: 30.5mm
  • Input Frequency: 440Hz
  • Input Voltage AC Max: 264V
  • Input Voltage AC Min: 90V
  • Leakage Current: 100µA
  • Length: 101.6mm
  • Line Regulation: 0.5%
  • Load Regulation: 1%
  • No. of Outputs: 3Outputs
  • Output Power Max: 60W
  • Output Ripple and Noise Voltage pk-pk: 1%
  • Power Supply Type: Switch Mode
  • Weight: 150g
  • Width: 50.8mm
