Omschrijving
PANASONIC - EEEFC0J102P - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 1000 µF, 6.3 V, 1000 hours @ 105°C, Polar
- AE Capacitor Case: Radial Can - SMD
- Capacitance: 1000µF
- Voltage Rating: 6.3V
- ESR: -
- Product Range: FC Series
- Lifetime @ Temperature: 1000 hours @ 105°C
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Ripple Current AC: 670mA
- Diameter: 10mm
- Height: 10.2mm
- Automotive Qualification Standard: AEC-Q200
- MSL: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance: ± 20%
- Capacitance Tolerance ±: ± 20%
- Capacitor Case Style: Radial Can - SMD
- Impedance: 0.15ohm
- Operating Temperature Range: -40°C to +105°C
- Power Factor: 0.26
