EEEFK1J470P Cap, 47µF, 63V, Radial, SMD Panasonic

PANASONICSKU:EEEFK1J470P Bestelcode:9696032

Prijs:
Actie prijs€1,79

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (6748 units)

Documenten en downloads

Omschrijving

PANASONIC - EEEFK1J470P - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 47 µF, 63 V, 2000 hours @ 105°C, Polar

  • AE Capacitor Case: Radial Can - SMD
  • Capacitance: 47µF
  • Voltage Rating: 63V
  • ESR: -
  • Product Range: FK Series
  • Lifetime @ Temperature: 2000 hours @ 105°C
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 105°C
  • Ripple Current AC: 250mA
  • Diameter: 8mm
  • Height: 10.2mm
  • Automotive Qualification Standard: AEC-Q200
  • MSL: -
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance: ± 20%
  • Capacitance Tolerance ±: ± 20%
  • Capacitor Case Style: Radial Can - SMD
  • External Length / Height: 10.2mm
  • Impedance: 0.65ohm
  • Operating Temperature Range: -55°C to +105°C
  • Operating life Time: 2000h
  • Power Factor: 0.08
  • Power Factor Frequency: 120Hz
  • Ripple Current Frequency: 100kHz
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 63V
