EEUFC1V221 Cap, 220µF, 35V, 20% Panasonic

PANASONICSKU:EEUFC1V221 Bestelcode:9692282

Prijs:
Actie prijs€0,93

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (13501 units)

Omschrijving

PANASONIC - EEUFC1V221 - Electrolytic Capacitor, 220 µF, 35 V, ± 20%, Radial Leaded, 3000 hours @ 105°C, Polar

  • Capacitance: 220µF
  • Voltage Rating: 35V
  • Product Range: FC Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 10mm
  • Lead Spacing: 5mm
  • Height: 12.5mm
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 105°C
  • Lifetime @ Temperature: 3000 hours @ 105°C
  • ESR: -
  • Automotive Qualification Standard: AEC-Q200
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 12.5mm
  • Impedance: 0.09ohm
  • Impedance Frequency: 100kHz
  • Impedance Temperature: 20°C
  • Lead Diameter: 0.6mm
  • No. of Pins: 2Pins
  • Operating Life Temperature: 105°C
  • Operating Temperature Range: -55°C to +105°C
  • Operating life Time: 3000h
  • Ripple Current AC: 755mA
  • Ripple Current Frequency: 100kHz
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 35V
