Omschrijving
PANASONIC - EEUFM0J122L - Electrolytic Capacitor, 1200 µF, 6.3 V, ± 20%, Radial Leaded, 4000 hours @ 105°C, Polar
- Capacitance: 1200µF
- Voltage Rating: 6.3V
- Product Range: FM Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 8mm
- Lead Spacing: 3.5mm
- Height: 20mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 4000 hours @ 105°C
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- External Diameter: 8mm
- External Length / Height: 20mm
- Impedance: 0.03ohm
- Impedance Temperature: 20°C
- Lead Diameter: 0.6mm
- Lead Length: 17mm
- Leakage Current: 0.01µA
- No. of Pins: 2Pins
- Operating Life Temperature: 105°C
- Operating life Time: 4000h
- Ripple Current AC: 1560mA
- Ripple Current Temperature: 105°C
