EEUFM1H221 Cap, 220µF, 50V, 20% Panasonic

PANASONICSKU:EEUFM1H221 Bestelcode:1219481

Prijs:
Actie prijs€1,49

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (25333 units)

Documenten en downloads

Omschrijving

PANASONIC - EEUFM1H221 - Electrolytic Capacitor, 220 µF, 50 V, ± 20%, Radial Leaded, 4000 hours @ 105°C, Polar

  • Capacitance: 220µF
  • Voltage Rating: 50V
  • Product Range: FM Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 10mm
  • Lead Spacing: 5mm
  • Height: 16mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 105°C
  • Lifetime @ Temperature: 4000 hours @ 105°C
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 16mm
  • Impedance: 0.03ohm
  • Impedance Temperature: 20°C
  • Lead Diameter: 0.6mm
  • Lead Length: 17mm
  • Leakage Current: 0.01µA
  • No. of Pins: 2Pins
  • Operating Life Temperature: 105°C
  • Operating Temperature Range: -40°C to +105°C
  • Operating life Time: 4000h
  • Ripple Current AC: 1650mA
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 50V
