EEUFR0J182B Cap, 1800µF, 6.3V, 20% Panasonic

PANASONICSKU:EEUFR0J182B Bestelcode:1800609

Prijs:
Actie prijs€0,55

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (240 units)

Documenten en downloads

Omschrijving

PANASONIC - EEUFR0J182B - Electrolytic Capacitor, 1800 µF, 6.3 V, ± 20%, Radial Leaded, 8000 hours @ 105°C, Polar

  • Capacitance: 1800µF
  • Voltage Rating: 6.3V
  • Product Range: FR Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 10mm
  • Lead Spacing: 5mm
  • Height: 16mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 105°C
  • Lifetime @ Temperature: 8000 hours @ 105°C
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance ±: ± 20%
  • Impedance: 0.028ohm
  • Impedance Frequency: 100kHz
  • Impedance Temperature: 20°C
  • Lead Diameter: 0.6mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +105°C
  • Ripple Current AC: 1790mA
  • Ripple Current Frequency: 100kHz
  • Ripple Current Temperature: 105°C
