PANASONIC - ETQP5M2R5YFC - Power Inductor (SMD), 2.5 µH, 15.1 A, Shielded, 27.2 A, PCC-M1054M Series, 10.7mm x 10mm x 5.4mm
- Inductance: 2.5µH
- RMS Current (Irms): 15.1A
- Inductor Construction: Wirewound
- Saturation Current (Isat): 27.2A
- Product Range: -
- Power Inductor Case: 10.7mm x 10mm x 5.4mm
- DC Resistance Max: 0.0059ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (07-Jul-2017)
- External Depth: 4.95mm
- External Length / Height: 10mm
- External Width: 10mm
- Height: 10mm
- Inductor Type: High Frequency
- No. of Pins: 2Pins
- Termination Type: Surface Mount Device
