FN2090B-20-08 Filter, Medical, 20A, Chassis Mount Schaffner

SCHAFFNERSKU:FN2090B-20-08 Bestelcode:1304869

Prijs:
Actie prijs€98,67

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (9 units)

Documenten en downloads

Omschrijving

SCHAFFNER - FN2090B-20-08 - Power Line Filter, Chassis, Medical, 250 VAC, 20 A, Single Phase, 2 Stage, Chassis Mount

  • Current Rating: 20A
  • Voltage Rating: 250V
  • Filter Type: Medical
  • Filter Terminals: Quick Connect
  • Inductance Min: 2.7mH
  • Capacitance: 1µF
  • Leakage Current Max: 2000pA
  • Product Range: -
  • SVHC: No SVHC (15-Jan-2019)
  • Bleed Resistor Resistance: 220kohm
  • External Depth: 45.4mm
  • External Length / Height: 113.5mm
  • External Width: 57.5mm
  • Height: 113.5mm
  • Inductance: 2.7µH
  • Leakage Current: 0.002µA
  • No. of Phases: Single Phase
  • Operating Temperature Max: 100°C
  • Operating Temperature Min: -25°C
  • Voltage Rating VAC: 250V
