FSCEX 150PF 1% 630V Cap, 150PF, 630V, 1%, PS, Through Hole LCR Components

LCR COMPONENTSSKU:FSCEX 150PF 1% 630V Bestelcode:9520686

Prijs:
Actie prijs€5,26

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (983 units)

Documenten en downloads

Omschrijving

LCR COMPONENTS - FSCEX 150PF 1% 630V - General Purpose Film Capacitor, Film / Foil PS, Axial Leaded, 150 pF, ± 1%, 250 V, 630 V

  • Capacitance: 150pF
  • Voltage Rating: 630V
  • Capacitor Dielectric Type: PS (Polystyrene)
  • Capacitance Tolerance: ± 1%
  • Product Range: FSC/EX Series
  • Capacitor Case Style: -
  • Capacitor Terminals: Axial Leaded
  • Lead Spacing: -
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • Body Diameter: 6mm
  • Capacitance Tolerance ±: ± 1%
  • Capacitor Application: Audio
  • Capacitor Mounting: Through Hole
  • External Length / Height: 12.5mm
  • Height: 12.5mm
  • Insulation Resistance: 10000Mohm
  • Lead Diameter: 0.8mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +85°C
  • Power Factor: 0.0005
  • Power Factor Frequency: 1kHz
  • Temperature Coeff. +: 110ppm/°C
  • Temperature Coeff. -: 50ppm/°C
  • Temperature Coefficient: -50ppm/°C to +110ppm/°C
  • Tolerance +: 1%
  • Tolerance -: 1%
  • Voltage Rating V DC: 630V
  • Voltage Rating VAC: 250V
