OMRON - G2RL-1-E-CF- DC24 - General Purpose Relay, G2RL Series, Power, Non Latching, SPDT, 24 VDC, 3 A
- Contact Configuration: SPDT
- Coil Voltage: 24VDC
- Contact Current: 16A
- Product Range: G2RL Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 240VAC
- Relay Terminals: Solder
- Contact Voltage VDC: 24VDC
- Contact Material: Silver Tin Oxide
- Coil Resistance: 1.44kohm
- Approval Bodies: CSA, VDE
- Approval Category: UL Recognised
- Approvals & Standards: CE, UL, VDE
- Coil Current: 16.7mA
- Coil Voltage VDC Nom: 24V
- Contact Current AC Max: 16A
- Contact Current DC Max: 16A
- Contact Current Max: 16A
- Contact Resistance: 100mohm
- Contact Voltage AC Max: 250V
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Max: 30V
- Contact Voltage DC Nom: 24V
- DC Coil Power: 400mW
- Dielectric Voltage Coil to Contact: 5000VAC
- Dielectric Voltage Contact to Contact: 1000VAC
- External Depth: 12.7mm
- External Height: 15.7mm
- External Length / Height: 15.7mm
- External Width: 29mm
- Insulation Resistance: 1000Mohm
- Insulation Resistance Voltage: 500VDC
- No. of Mechanical Operations: 20000000
