G2RL-1A-E-CV DC12 Relay, SPST-NO, 250VAC, 24Vdc, 16A Omron

OMRONSKU:G2RL-1A-E-CV DC12 Bestelcode:1695877

Prijs:
Actie prijs€5,10

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (3486 units)

Documenten en downloads

Omschrijving

OMRON - G2RL-1A-E-CV DC12 - General Purpose Relay, G2RL Series, Power, Non Latching, SPST-NO, 12 VDC, 16 A

  • Contact Configuration: SPST-NO
  • Coil Voltage: 12VDC
  • Contact Current: 16A
  • Product Range: G2RL Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 24VDC
  • Contact Material: Silver Tin Oxide
  • Coil Resistance: 360ohm
  • Approvals & Standards: CE, UL, VDE
  • Coil Current: 20.8mA
  • Coil Operating Lower Percent Limit: 10%
  • Coil Operating Upper Percent Limit: 70%
  • Coil Voltage VDC Nom: 12V
  • Contact Current AC Max: 16A
  • Contact Current DC Max: 16A
  • Contact Current Max: 16A
  • Contact Voltage AC Max: 440V
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Max: 300V
  • Contact Voltage DC Nom: 24V
  • DC Coil Power: 250mW
  • External Depth: 29mm
  • External Height: 15.7mm
  • External Length / Height: 15.7mm
  • External Width: 12.7mm
  • Nom Operating Power: 400mW
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -40°C
  • Operating Time: 15ms
  • Relay Type: Power
  • Release Time: 5ms
  • Switching Current AC Max: 16A
  • Switching Current DC Max: 16A
