G5V-2 DC24 Relay, Signal, DPDT, 30Vdc, 2A Omron

OMRONSKU:G5V-2 DC24 Bestelcode:9949500

Prijs:
Actie prijs€4,94

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (18925 units)

Documenten en downloads

Omschrijving

OMRON - G5V-2 DC24 - Signal Relay, 24 VDC, DPDT, 2 A, G5V-2, Through Hole, Non Latching

  • Coil Voltage: 24VDC
  • Contact Configuration: DPDT
  • Contact Current: 2A
  • Product Range: G5V-2 Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Relay Terminals: Solder
  • Contact Voltage VAC: 125V
  • Contact Voltage VDC: 30V
  • Contact Material: Silver
  • Coil Resistance: 1.152kohm
  • Approval Bodies: CSA, UL
  • Approval Category: FCC Part 68
  • Approvals & Standards: CSA, UL
  • Coil Current: 20.8mA
  • Coil Power Continuous: 500mW
  • Coil Voltage VDC Nom: 24V
  • Contact Current AC Max: 500mA
  • Contact Current Max: 2A
  • Contact Voltage AC Nom: 125V
  • Contact Voltage DC Nom: 30V
  • External Depth: 20.5mm
  • External Height: 11.5mm
  • External Width: 10.1mm
  • Operating Temperature Max: 65°C
  • Operating Temperature Min: -25°C
  • Operating Time: 7ms
  • Release Time: 3ms
