Omschrijving
OMRON - G6CK-1114P-US DC12 - General Purpose Relay, G6C Series, Power, Latching Dual Coil, SPST-NO, 12 VDC, 10 A
- Contact Configuration: SPST-NO
- Coil Voltage: 12VDC
- Contact Current: 10A
- Product Range: G6C Series
- Relay Mounting: Through Hole
- Coil Type: Latching Dual Coil
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: 30VDC
- Contact Material: Silver Alloy
- Coil Resistance: 514ohm
- Approvals & Standards: CSA, UL, VDE
- Coil Current: 23.3mA
- Coil Voltage VDC Nom: 12V
- Contact Current Max: 10A
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Nom: 125V
- External Depth: 20mm
- External Height: 10mm
- External Width: 15mm
- Nom Operating Power: 280mW
- Relay Type: Power
