OMRON - G7L-2A-T DC24. - Power Relay, DPST-NO, 24 VDC, 25 A, G7L, Panel Mount, Non Latching
- Contact Configuration: DPST-NO
- Coil Voltage: 24VDC
- Contact Current: 25A
- Product Range: G7L Series
- Relay Mounting: Panel
- Coil Type: Non Latching
- Contact Voltage VAC: 277VAC
- Relay Terminals: Quick Connect
- Contact Voltage VDC: -
- Contact Material: Silver Alloy
- Coil Resistance: 303ohm
- Approval Bodies: CSA, IEC, UL, VDE
- Approvals & Standards: CSA, IEC, UL
- Coil Current: 79mA
- Coil Operating Lower Percent Limit: 75%
- Coil Operating Upper Percent Limit: 110%
- Coil Voltage VDC Nom: 24V
- Contact Current AC Max: 25A
- Contact Current Max: 25A
- Contact Voltage AC Max: 220V
- Contact Voltage AC Nom: 220V
- DC Coil Power: 1.9W
- External Depth: 47mm
- External Height: 52.5mm
- External Length / Height: 52.5mm
- External Width: 33.5mm
- Nom Operating Power: 1.9W
- Operating Temperature Max: 60°C
- Operating Temperature Min: -25°C
- Relay Type: Power - General Purpose
