GP2500-0.125-02-0404 Gap Pad 2500, .125", 4"x4" Sheet BERGQUIST

BERGQUISTSKU:GP2500-0.125-02-0404 Bestelcode:8783519

Prijs:
Actie prijs€114,66

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (54 units)

Documenten en downloads

Omschrijving

BERGQUIST - GP2500-0.125-02-0404 - Thermally Conductive Material, Gap Pad 2500, .125", 4" x 4" Sheet, 2.7 W/m.K, 3.18 mm, 0.74 °C/W

  • Thermal Conductivity: 2.7W/m.K
  • Conductive Material: Filled Silicone Polymer
  • Thickness: 3.18mm
  • Thermal Impedance: 0.74°C/W
  • Dielectric Strength: -
  • External Length: 101.6mm
  • External Width: 101.6mm
  • Product Range: -
  • SVHC: No SVHC (27-Jun-2018)
  • Breakdown Voltage Vbr: 6kV
  • Colour: Brown
  • Dielectric Constant: 6.8
  • External Depth: 3.175mm
  • Flammability Rating: UL94V-0
  • Insulator Body Material: Gap Pad 2500 S80
  • Length: 100mm
  • Material: Gap Pad 2500 S80
  • Operating Temperature Max: 200°C
  • Operating Temperature Min: -60°C
  • Operating Temperature Range: -60°C to +200°C
  • Overall Width: 100mm
  • Resistivity: 10ohm/sq
  • Rockwell Hardness: 80
  • Specific Gravity: 3.1
  • Type: Thermal Pad
  • Volume Resistivity: 100000Mohm-m
