Omschrijving
BROADCOM - HDSP-N103 - 7 Segment LED Display, Red, 20 mA, 1.8 V, 3.5 mcd, 1, 20 mm
- LED Colour: Red
- Forward Current If: 20mA
- Forward Voltage: 1.8V
- Luminous Intensity: 3.5mcd
- No. of Digits / Alpha: 1
- Character Size: 20mm
- Common Connection: Common Cathode
- Product Range: -
- SVHC: No SVHC (15-Jan-2018)
- Background Colour: Grey
- Character Type: .8.
- Current If Luminous Intensity: 5mA
- External Depth: 8.38mm
- External Length / Height: 27.69mm
- External Width: 19.96mm
- Forward Current If Max: 20mA
- Forward Voltage VF Max: 1.6V
- Forward Voltage per Segment @ If: 1.6V
- Lead Spacing: 2.54mm
- Luminous Intensity per Segment @ If Max: 3.5mcd
- Luminous Intensity per Segment @ If Min: 0.59mcd
- Luminous Intensity per Segment @ If Typ: 3.5mcd
- Nom Current If per Segment: 1mA
- Operating Temperature Max: 105°C
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +105°C
- PIV Max: 3V
- Peak Forward Current: 45mA
- Row Pitch: 15.24mm
