HF3-52 Relay, SPDT, 220VAC, 2A AXICOM - Te Connectivity

AXICOM - TE CONNECTIVITYSKU:HF3-52 Bestelcode:9913580

Prijs:
Actie prijs€20,94

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (359 units)

Documenten en downloads

Omschrijving

AXICOM - TE CONNECTIVITY - 1-1462051-6 - General Purpose Relay, HF3 Series, High Frequency, Non Latching, SPDT, 4.5 VDC, 2 A

  • Contact Configuration: SPDT
  • Coil Voltage: 4.5VDC
  • Contact Current: 2A
  • Product Range: HF3 Series
  • Relay Mounting: SMD
  • Coil Type: Non Latching
  • Contact Voltage VAC: 220VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: -
  • Contact Material: Silver
  • Coil Resistance: 145ohm
  • Coil Frequency Max: 3GHz
  • Coil Voltage VDC Nom: 4.5V
  • Contact Current AC Max: 1A
  • Contact Current Max: 2A
  • Contact Resistance: 100mohm
  • Contact Voltage AC Max: 125V
  • Contact Voltage AC Nom: 125V
  • Contact Voltage DC Max: 60V
  • Contact Voltage DC Nom: 60V
  • DC Coil Power: 140mW
  • Dielectric Voltage Coil to Contact: 1000VAC
  • Dielectric Voltage Contact to Contact: 600VAC
  • External Depth: 14.6mm
  • External Height: 10mm
  • External Length / Height: 10mm
  • External Width: 7.2mm
  • IP / NEMA Rating: IP67
  • Impedance: 50ohm
  • Insertion Loss Max: -0.35dB
  • Insulation Resistance: 100Mohm
  • Mechanical Life: 10 x 10? operations
  • No. of Pins: 16Pins
  • Operating Frequency Max: 3GHz
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -55°C
  • VSWR: 1.2
