XP POWER - IA0515D - Isolated Through Hole DC/DC Converter, ITE, 1:1, 1 W, 2 Output, 15 V, 33 mA
- No. of Outputs: 2 Output
- Output Power Max: 1W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 33mA
- Output Voltage - Output 2: -15V
- Output Current - Output 2: 33mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: IA Series
- Input Voltage DC Min: 4.5V
- Input Voltage DC Max: 5.5V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 10.16mm
- Height: 6.35mm
- Depth: 20.32mm
- SVHC: No SVHC (15-Jan-2018)
- Efficiency Max: 80%
- Isolation Voltage: 1kV
- Line Regulation: 1.2%
- Load Regulation: 8%
- No. of Outputs: 2Outputs
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Output Voltage +: 15VDC
- Output Voltage -: -15V
- Power Rating: 1W
- Supply Voltage: 5V
