IE1212D Converter, DC/DC, 1W, 12V XP Power

XP POWERSKU:IE1212D Bestelcode:8727767

Prijs:
Actie prijs€5,25

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (16 units)

Documenten en downloads

Omschrijving

XP POWER - IE1212D - Isolated Through Hole DC/DC Converter, 1kV Isolation, ITE, 1:1, 1 W, 1 Output, 12 V, 84 mA

  • No. of Outputs: 1 Output
  • Output Power Max: 1W
  • Output Voltage - Output 1: 12V
  • Output Current - Output 1: 84mA
  • Output Voltage - Output 2: -
  • Output Current - Output 2: -
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: IE Series
  • Input Voltage DC Min: 10.8V
  • Input Voltage DC Max: 13.2V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 10.14mm
  • Height: 6.86mm
  • Depth: 12.7mm
  • SVHC: No SVHC (15-Jan-2018)
  • Efficiency Max: 80%
  • Isolation Voltage: 1kV
  • Line Regulation: 1.2%
  • Load Regulation: 8%
  • No. of Outputs: 1Outputs
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -40°C
  • Output Voltage Min: 10.8V
  • Power Rating: 1W
  • Supply Voltage: 12V
