Omschrijving
VISHAY - IHLP2525CZER1R0M11 - Power Inductor (SMD), 1 µH, 12.5 A, Shielded, 9.5 A
- Inductance: 1µH
- RMS Current (Irms): 12.5A
- Inductor Construction: Shielded
- Saturation Current (Isat): 9.5A
- Product Range: -
- Power Inductor Case: 6.86mm x 6.47mm x 3mm
- DC Resistance Max: 0.008ohm
- Inductance Tolerance: ± 20%
- External Depth: 6.47mm
- External Length / Height: 0.118mm
- External Width: 6.86mm
- Height: 0.118mm
- Inductor Type: High Current
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
